Interface
2x 10/100Mbps Ethernet ports (RJ45)

Button / Switch
1x WPS/Pairing button

1x Reset Button

1x Operation Mode Switch

1x Power On/Off Switch

LED
1x Wi-Fi Signal and Status

Power Consumption Approximately 3W
Power Option Direct wall-plug
Rated Voltage/Frequency Input: 100 - 240 VAC, 50/60Hz

WIRELESS
Wireless Channels / Frequency
2.4GHz: 1 ~ 13 (2412 - 2462 MHz)

Wireless Channel Bandwidth
2.4GHz: 20/40MHz

Wireless Coverage
Up to 1000 sq. ft. (indoor)

Wireless Standards IEEE 802.11b/g/n
Wireless Frequency Band 2.4GHz Wireless-N
Wireless Link Rate
11n: Up to 300Mbps (dynamic)

11b: Up to 54Mbps (dynamic)

11g: Up to 11Mbps (dynamic)

Wireless Transmit Power
< 20dBm (EIRP)

Wireless Antenna
2x Internal 3dBi Antenna

Wireless Security
64/128/152-bit WEP

WPA-PSK / WPA2-PSK

SOFTWARE
Internet (WAN) Connection
Type
Repeater mode

AP mode

Router mode (Dynamic IP, Static IP, PPPoE)

Device Management
Web Browser / Mobile UI

Domain Login

DHCP Setting
DHCP Server, DHCP Client

Wireless Functions
WMM (Wi-Fi Multimedia)

Wireless MAC Address Filtering

Wireless Statistics

DIMENSION & WEIGHT
Dimension 99 x 60 x 70 mm (L x W x H)
Weight 150g
PACKAGE CONTENT
1 x PEN1201 Wi-Fi Extender

1 x Quick Installation Guide

1 x RJ-45 LAN Cable

SPESIFIKASI :

Ouput Power Capacity : 1200VA / Up to 840 Watt
Output Power Voltage : 220V AC (rating), 220VAC 17~22% (Battery Mode) Freq: 50HZ 1Hz (Battery Mode)
Input Power Voltage : 140 ~ 285V, Frequency Range 40Hz - 70Hz, Phase : Single + GND
Transfer Time : 2ms Typical
Back-Up Time : 8~40 Minutes (depending on load), 90% Capacity after 8 hrs Charging Time
Battery Type : Maintenance Free-Sealed Lead-Acid Battery with Suspended Electrolyte (Leakproof)
Dataline Protection : RJ-11 Mode/Fax/DSL Protection (Two Wire Single Line)
Power Factor : Up to 0.7
Indicator LED : Normal Mode, Back-Up Mode, Charging Mode
Input Interface : 1x IEC 320 C13
Output Interface : 3x IEC 320 C13 (Battery), 1x Standard AC Outlet (Bypass Outlets)
Software Support : Available
Software Interface : COM/Serial Port
Protection Avaibility : Short Circuit Protection, Surge Protection, Overload & Temperature Protection, AVR
Other Features : Intelligent Battery Management, Short Circuit Software protection (CPU)
Dimension (WHD) : 44.5(W) x 19.5(H) x 30(D) mm

The Tenda TEG1016D 16 port RJ45 10/100/1000 Mbps auto-negotiation, dengan kapasitas hingga 2000 Mbps dari nilai transmisi komunikasi full- duplex, semua port mendukung line- speed forwarding, dan kapasitas chace yang besar turut memastikan transfer data tepat waktu dari file berukuran besar dan streaming video yang stabil. Terus terkoneksi selama 7 hari dalam 24 jam.

Standar & Protokol : IEEE 802.3、IEEE 802.3u、IEEE 802.3x、IEEE 802.3ab
Tipe Pemasangan Kabel : Category 5e or better
Port : 16*10/100/1000M Base-T Ethernet ports (Auto MDI/MDIX)
LED: 1*Power，16*Link/Act
Ukuran: 294mm×178mm×44mm , 1U height
Pilihan Penyangga: Desktop or rack mount
Mode Pengalihan: Store and Forward
Tabel Alamat MAC: 8K
Kapasitas Sakelar: 32Gbps / non-blocking
Kapasitas Pengalihan: 23.8 mpps
Proteksi petir : 6KV for power supply ，6KV for all RJ45 ports
Persediaan Daya Listrik : 100~240V AC，50/60Hz
Suhu: Operating|Storage temperature:-10°C~45°C | -40°C~70°C
Kelembapan: Operating|Storage humidity:10%~90% RH（noncondensing） | 5%~90% RH（noncondensing）

Deskripsi Tenda Switch Hub S105 5 Port
Switch Hub S105 5 Port

Tenda 5-port Ethernet Switch S105 merupakan switch desktop yang dirancang khusus untuk keluarga, kantor, asrama dan sebagainya. Port auto-negotiation 5* 10/100 M dengan rate dupleks penuh hingga 200Mbps membawa akses internet yang sangat cepat. Rancangan plug-and-play membuat pemasangan dilakukan dengan mudah tanpa membuang waktu. Apakah anda penggemar teknologi atau pengguna pertama, S105 sangatlah mudah untuk diatur tanpa operasi yang menghabiskan waktu.

- Standar & Protokol : IEEE 802.3, IEEE 802.3u, IEEE 802.3x

- Dimensi : 82.00mm*52.00mm*22.30mm

- Port 5*10/100M auto-negotiation RJ 45 ports (Auto MDI/MDIX)

- Media Transmisi :
10Base-T: UTP Cat 3( or better)
100Base-TX: UTP Cat5

- Tingkat Pengalihan Paket :
10Mbps：14880pps
100Mbps：148800pps

- Sertifikasi :
CE
FCC
RoHS


Isi Paket
1* Installation Guide
1 * 5-port Ethernt Switch
1* Power Adapter (5V0.6A)

Tenda TEG1024D 24 Port RJ45 10/100/1000 Mbps auto-negotiation, dengan kapasitas hingga 2000 Mbps dari nilai transmisi komunikasi full- duplex, semua port mendukung line- speed forwarding, dan kapasitas chace yang besar turut memastikan transfer data tepat waktu dari file berukuran besar dan streaming video yang stabil. Terus terkoneksi selama 7 hari dalam 24 jam.

Standar & Protokol
IEEE 802.3IEEE 802.3uIEEE 802.3xIEEE 802.3ab
Tipe Pemasangan Kabel
Category 5e or better
Port
24*10/100/1000M Base-T Ethernet ports (Auto MDI/MDIX)
LED
1*Power24*Link/Act
Ukuran
294mm178mm44mm , 1U height
Pilihan Penyangga
Desktop or rack mount
Mode Pengalihan
Store and Forward
Tabel Alamat MAC
8K
Kapasitas Sakelar
48Gbps / non-blocking
Kapasitas Pengalihan
35.7 mpps
Proteksi petir
6KV for power supply 6KV for all RJ45 ports
Persediaan Daya Listrik
100~240V AC50/60Hz
Suhu
Operating|Storage temperature:-10C~45C | -40C~70C
Kelembapan
Operating|Storage Humidity:10%~90% RHnoncondensing | 5%~90% RHnoncondensing

Tenda PoE Switch TEF1109P-8-63W

TEF1109P-8-63W Up to 250 meters long distance transmission, beyond hundred meters transfer limit.6KV lighting protection PoE switch is the real monitoring private switch .Ports 1-8 support IEEE 802.3at and IEEE 802.3af PoE standard. It provides 30W maximum PoE output a single port and 58W the whole device.

- Standar & Protokol :
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE802.3ab, IEEE 802.3af, IEEE 802.3at

- Dimensi : 177.5mm x 104mm x 26mm

- Indikator :
Link/Act, PoE Status, Power, 100M

- Port :
8 10/100Base-TX RJ45 Ports(Data/Power)
1 10/100Base-TX RJ45 Port(Data)

- Proteksi Petir : 6KV

- Manajemen persediaan PoE :
Port 1 to Port 8 support standard IEEE802.3at/af power( maximum power for each port is 30W)，PoE power type is end-span(1245 , 3678- line pair)
in full configuration：<63W
PoE Max Power Supply：58W

Data Rates
300Mbps
Interface 1 10/100 LAN Port
Frekuensi 2.4GHz
Enkripsi

Wi-Fi Protected Access (WPA™, WPA2™)
Wi-Fi Protected Setup™ (WPS) : WPS Push Button

Antena 2x 2 dBi Gain detachable omnidirectional antennas with RP-SMA connector
Standar Protokol

IEEE 802.11n/g/b wireless LAN
IEEE 802.3/802.3u

Fitur

Membuat atau Perluas Jaringan Nirkabel di Rumah Anda atau Kantor
Mudah Instal dan Hubungkan dengan Wi-Fi Protected Setup ™
Secure Wireless Enkripsi Menggunakan WPA/WPA2 Keamanan
Beberapa mode: Access Point, Jembatan dengan Access Point, Repeater, atau Client Wireless
